System Map: Left View 1 - 11
1
System Map: Left View
Figure 1 - 5 - Left View
1. External Monitor
Port
2. S-Video-Out Jack
3. Cable (CATV)
Antenna Jack
*
4. RJ-11 Phone
Jack
5. RJ-45 LAN Jack
6. Mini-IEEE 1394
Port
7. Express Card
Slot
8. Optical Device
Drive Bay (for
CD/DVD Device)
9. 7-in-1 Card
Reader
* Enabled with Optional
Mini-PCI TV Tuner Only
3
1 5 2 4
6
7
8
9
Mini-IEEE 1394 Port
The Mini-IEEE 1394 port only supports SELF POWERED IEEE 1394 devices.
ExpressCard Slot
The ExpressCard Slot accepts either ExpressCard/34 or ExpressCard/54 formats.
7-in-1 Card Reader
The card reader allows you to use the most popular digital storage card formats:
MMC (MultiMedia Card) / SD (Secure Digital) / MS (Memory Stick) /
MS Pro (Memory Stick Pro) / MS Duo (requires PC adapter) /
Mini SD (requires PC adapter) / RS MMC (requires PC adapter)
