Disassembly
2 - 8 Removing the Hard Disk Drive
2.Disassembly
Removing the Hard Disk Drive
The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 9.5mm
or 7mm (h). Follow your operating system’s installation instructions, and install all necessary drivers and utilities (as
outlined in Chapter 4 of the User’s Manual) when setting up a new hard disk.
Hard Disk Upgrade Process
Figure 4
HDD Assembly
Removal
a. Remove the screws.
b. Remove the cover.

3. Hard Disk Bay Cover
• 2 Screws
1. Turn off the computer, turn it over.
2. Locate the hard disk bay cover and remove screws - from the bottom cover ( Figure 4a ) .
3. Slide the bay cover until the cover and case indicators are aligned ( Figure 4b ).
1 2
3 4
a.

HDD System Warning
New HDD’s are blank. Before you
begin make sure:
You have backed up any data
you want to keep from your old
HDD.
You have all the CD-ROMs and
FDDs required to install your op-
erating system and programs.
If you have access to the internet,
download the latest application
and hardware driver updates for
the operating system you plan to
install. Copy these to a remov-
able medium.
2 1
4
b.
3
4
