59
efficiency. At least once a year, the fan should be removed for cleaning. During cleaning it should be determined if
lubrication of the electrical motor is required. High temperature blower motor systems are lubricated at the factory. These
motors should require no further lubrication; however, at higher inlet temperatures, increased bearing life can be achieved
by annually re-lubricating the motors with 10 to 20 drops of Anderol Number 465 high temperature synthetic lubricant.
DO NOT USE petroleum-based oil, as premature bearing failure will result.
ROOM AIR BLOWER TESTING
Several steps are required to verify the correct operation of a blower system associated with Country Flame catalytic
stoves. Several additional components have been provided in the blower system to assist the homeowner in testing a
catalytic stove blower system. The following general information is provided as steps to be followed in testing a blower
system. Refer to the schematics provided with this manual for more detailed information. If problems occur, contact a
local Country Flame dealer, Country Flame, or a certified electrician to determine the cause of the problem.
1
Check the automatic fan switch thermal snap disc. Ensure this switch has not been broken during shipment. Check
its electrical connections for any loose connections or shorts.
2
Use a hair dryer to heat the thermal snap disk to approximately 110ºF. When a click is heard, that means the snap
disk has closed and the blower system should begin to operate. WARNING: 120 Volts AC is available at the snap disk
terminals. Caution should be used and if unfamiliar or unqualified to deal with household voltages and currents contact a
qualified electrician.
3
If the blower system fails to operate after completing step 2, remove the power cord from the wall and then
bypass the automatic snap disk (fan switch). This can be done by providing a jumper to the wires on each side of the snap
disk. Again, if unqualified, contact an electrician. Ensure that the fan switch is not in the off position. Reinstall the
power cord in the wall outlet and if the blower system begins to operate, replace the defective automatic fan switch and
wire it correctly.
4
If the blower system still does not operate, unplug the power cord and bypass the 3-speed fan switch. Once
bypassed, reinstall the power cord into the wall socket. If the blower system begins to operate when power is restored,
replace the 3-speed switch and restore the connection to the automatic fan switch described in Step 3.
5
If the blower system is still not operative, contact a local Country Flame dealer, Country Flame or a qualified
electrician.
6
The R model is equipped with an optional blower unit that is mounted on the back of the stove and easily
accessible.
7
The O2 model is equipped with two standard blowers located on the left and right of the stove.
8
The models B and BBF are equipped with a standard blower tray that is located below the ash lip of the stove.
BLOWER MALFUNCTION
In the event of any malfunction in the electrical system of your insert/stove, please refer to previous section, electrical
system checklist, and blower schematics for wiring details.
NO ELECTRICITY
In the event of a power failure, the catalytic stove will continue to generate heat into the home. This is because the
catalytic stove will pull cold air into the bottom of the stove and heat it up. As the air is heated, it rises and pulls itself
through the stove and into the room. This is called gravity airflow or convection heat. The homeowner can enhance the
amount of heat coming from the stove by performing the following (BBF and B only):
1
Unplug the stove’s power cord from the wall receptacle.
2
Remove the blower tray assembly by loosening the two screws beneath the ash fender.
