41
INSERT HEIGHT 23.5”/ 597 mm
INSERT DEPTH 23.5”/ 597 mm
WIDTH AT FRONT 33.25”/ 845 mm
WIDTH AT FIREPLACE
OPENING
22” / 539 mm
WIDTH AT REAR 28” / 711 mm
HANDLE DEPTH 7.5” / 184 mm
HEARTH EXTENSION Adjustable
FLUE SIZE, I.D. 8” / 203 mm
DEPTH TO FLUE CRT
(From back of stove)
14.0625” / 357 mm
WEIGHT WITH BRICK 540 pounds / 268 kg
LEG FRAME HEIGHT 6.125”/ 156 mm
SHROUD WIDTH 46.75” / 1187 mm
SHROUD HEIGHT 31.375” / 797 mm
EPA EFFICIENCY 72%
EPA BTU RANGE 10,400 to 55,500
COMBUSTION AIR CONTROL Manual
EMISSION RATE (grams/hour) 2.0
LOG LENGTH, MAXIMUM 24” / 610 mm
FIREBOX VOLUME 3.4 cubic feet
BLOWER ASSEMBLY 600 cubic feet per minute
WARNOCK HERSEY TEST REPORT 632-936200
NOTE: ALL SPECIFICATIONS ARE APPROXIMATE AND SUBJECT TO CHANGE WITHOUT NOTICE.
