installation instructions. Contact Country Flame or a local authorized dealer to resolve any questions or installation
procedures. TABLE 8 shows the required components needed for a typical mobile home installation. Contact a
Dura-Vent authorized dealer for the latest specifications and cost for these mobile home chimney system parts or
purchase a Mobile Home Kit Number 6DP-MH6” from the same Dura-Vent dealer.
TABLE 8: MOBILE HOME (minimum) CHIMNEY SYSTEM REQUIRED PARTS
FIGURE 12
ITEM NUMBER PART NUMBER
DESCRIPTION
QTY
1 SDP-C-9084 SPARK ARRESTOR CHIMNEY CAP 1
4 SDP-F-9049V 0/12 – 6/12 ADJUSTABLE ROOF FLASHING 1
4 (alternate) SDP-F-9051V ROOF FLASHING, Flat (vs. SDP-F-9049V) 1
9/10 (alternate) SDP-S-9047N + TRIM CEILING SUPPORT BOX, Flat 1
9/10 SDP-SB-9048AN + TRIM CEILING SUPPORT BOX, Square (vs. SDP-SB-9048AN) 1
2 SDP-P-9121SS 24” CHIMNEY SECTION 2
5 SDP-IS-9946 ATTIC INSULATION SHIELD (ONLY IF NEEDED) 1
8 CERAFORM 126 WALL PROTECTION ( IF REQUIRED) 1
3 SDP-SC-9959 STORM COLLAR 1
6/7 DVL-8646 DOUBLE WALL ADJUSTABLE OR FIXED STOVEPIPE 1/2
11 DVL-8674 CLOSE CLEARANCE ADAPTER (not shown, Fig 12) 2
NOTE: The information provided in TABLE 8 and detailed in FIGURE 12 are for informational purposes. These chimney
system parts may or may not be needed depending on site-specific conditions found in the homeowner’s application.
Consult a professional and insure that any installation meets all federal, state, and local building codes. Failure to follow
the chimney manufacturer’s installation instructions will void Country Flame’s product warranty and can have adversely
impact on the homeowner’s insurance policy. Contact Country Flame or one of its local authorized dealers to resolve any
questions about installation or parts usage.
