開孔尺寸
DOP-B05S100
184(7.24")
144
(5
.67")
43.3
T
172.4+1(6.79"+0.04")
1
32.
4+
1(
5.2
1"
+
0.04") Note:
T=1.6mm(0.063")~
6mm(0.24")
DOP-B07S200／DOP-B07S201／DOP-B07E205
215.0
161.
0
T
40.5
196.9 +1.0
14
2.
9 +1.
0
4-R3
(8.46")
(6.
3
4"
)
(7.75" +0.04")
(5
.6
3"
+
0.0
4"
)
NOTE:
T=1.6 mm(0.063")~
6 mm(0.24")
單位： mm (inches)
單位： mm (inches)
