English-13
Specifications
MODEL DOP-B05S100 DOP-B07S200 DOP-B07S201 DOP-B07S211 DOP-B07E205 DOP-B07E215
Display Type
5.6” TFT LCD
(65536 colors)
7” Wide Screen TFT LCD (65536 colors)
Resolution
320 x 234
pixels
480 x 234 pixels
Backlight
LED Backlight
(less than
50,000 hours
half-life at
25
o
C) (Note 1)
CCFL Backlight
(less than
50,000 hours
half-life at
25
o
C) (Note 1)
LED Backlight (less than 20,000 hours half-life at 25
o
C) (Note 1)
L
CD MODUL
E
Display Size
5.6" (113.28 x
84.70mm)
7" (154.08 x 86.58mm)
Operation System Windows Base Real Time OS
MCU 32-bit RISC Micro-controller
NOR Flash ROM NOR Flash ROM 4 Mbytes (System: 1MB / User: 3MB)
SDRAM 8Mbytes 16Mbytes
Backup Memory
(Bytes)
128K 256K
Buzzer Multi-Tone Frequency (2K ~ 4K Hz) /85dB Sound
Effect
Output AUX N/A N/A N/A N/A Stereo output Stereo output
Ethernet Interface N/A N/A N/A N/A
IEEE 802.3,
IEEE 802.3u
10/100 Mbps
auto-sensing
(has built-in
isolated power
circuit (Note 3) )
IEEE 802.3,
IEEE 802.3u
10/100 Mbps
auto-sensing
(has built-in
isolated power
circuit (Note 3) )
Memory Card N/A N/A N/A N/A SD Card SD Card
USB 1 USB Host (Note 2) Ver 1.1 / 1 USB Client Ver 1.1
COM1 RS-232 (support hardware flow control)
COM2
RS-232 /
RS-485
RS-232 / RS-422 / RS-485
RS-232 / RS-422 / RS-485
(has built-in isolated power
circuit
(Note 3)
)
Serial
COM
Port
COM3
RS-422 /
RS-485
RS-232 / RS-422 / RS-485
RS-232 / RS-422 / RS-485
(has built-in isolated power
circuit (Note 3) )
Function Key N/A User defined key x 4 + System key x 4
Perpetual Calendar
(RTC)
Built-in
Cooling Method Natural air circulation
Safety Approval
(Waterproof for
front panel)
IP65 / NEMA4 / CE, UL (Note 4)
Operation Voltage
(Note 5)
DC +24V (-10% ~ +15%)
(please use isolated power supply)
DC +24V (-10% ~ +15%)
(has built-in isolated power
circuit
(Note 3)
)
