Identifying external components, Front panel – D-Link DFE-2600 User Manual
Page 19
Unpacking and Setup
7
Inspect the hub and all accompanying items. If any item is damaged or
missing, report the problem to your D-Link dealer.
Identifying External Components
This section identifies all the major external components of the hub. Both the
front and rear panels are shown, followed by a description of each panel fea-
ture. The indicator panel is described in detail in the next chapter.
Front Panel
DFE-2624i / DFE-2624ix Front Panel
DFE-2624 / DFE-2624x Front Panel
DFE-2616i / DFE-2616ix Front Panel
DFE-2616 / DFE-2616x Front Panel
