CONTROL THE PROJECTOR
The projector has two types of operation: DIRECT OPERATION and MENU OPERATION. DIRECT OPERATION
allows you to operate the projector by using one button without showing the MENU. In MENU OPERATION mode,
you display menus where you can adjust the projector’s settings. Follow the instruction for each control.
DIRECT OPERATION
ADJUST ITEM
TOP CONTROL
OF THE PROJECTOR
REMOTE CONTROL UNIT
POWER (LAMP) ON/OFF POWER BUTTON POWER BUTTON
VIDEO MODE SELECT MODE BUTTON MODE BUTTON
VOLUME ADJUSTMENT VOLUME (+) and ( - ) BUTTONS VOLUME (+) and ( - ) BUTTONS
SOUND MUTE NOT AVAILABLE MUTE BUTTON
ZOOM ADJUSTMENT ZOOM/FOCUS BUTTON
LEVEL (+) and ( - ) BUTTONS
ZOOM (+) and (- ) BUTTONS
FOCUS ADJUSTMENT ZOOM/FOCUS BUTTON
LEVEL (+) and (- ) BUTTONS
FOCUS (+) and ( - ) BUTTONS
NORMAL PICTURE NORMAL BUTTON NOT AVAILABLE
FREEZE PICTURE NOT AVAILABLE FREEZE BUTTON
COLOR SYSTEM SYSTEM BUTTON Refer to the Menu operation.
MENU OPERATION
1. COMPUTER MODE
ADJUST ITEM
TOP CONTROL
OF THE PROJECTOR
REMOTE CONTROL UNIT
OOMPUTER SYSTEM SYSTEM BUTTON
LEVEL (+) BUTTONS
MENU BUTTON
POINT (UP/DOWN) BUTTON
REAR CLICK BUTTON
PICTURE IMAGE
BRIGHTNESS
CONTRAST
H-POSITION
V-POSITION
FINE SYNC.
MENU BUTTON
LEVEL (+) and ( - ) BUTTONS
MENU BUTTON
POINT (UP/DOWN) BUTTON
REAR CLICK BUTTON
PICTURE SCREEN NOT AVAILABLE MENU BUTTON
POINT (UP/DOWN) BUTTON
REAR CLICK BUTTON
PC ADJUSTMENT NOT AVAILABLE MENU BUTTON
POINT (UP/DOWN) BUTTON
REAR CLICK BUTTON
2 2 ■
