This profector is adjustable to different types of computer display signals based on VGA. SVGA or XGA >
•COMPATIBLE COMPUTER SPECIFICATIONS' on the next page). If you set MODE SELECT to
'C“'V
the projector will automatically process the incoming signal and project the proper image withoc
setting. Although this will work in most cases, you may be required to manually set the pro)ectu>
computer signals. If the computer image is not reproduced property, try the following procedure and swiu
computer display mode that you want to use.
1. Connect the computer and the projector, and turn them on.
2. Set MODE SELECT to ‘COMPUTER MODE*. This shows the current display mode initlaly detectec
projector in the system window. And 'Current mode* rfisplay appears.
NOTE: 1. If the projector cannot discrirrinate or detect the input signal from the computer, the 'Go F
display appears.
NOTE: 2. If
no input Signal from the computer,
the *No
signar display appears on the screen.
3. Press MENU button and MAIN MENU DISPLAY dialoo box wil appear
4. Press PÜINI Lbf-r/RiGKT bulton(s) to select SYSTEM and press SELECT button. Ar>other dial
COMPUTER SYSTEM DISPLAY will appear.
5. Press POINT DOWN button and a red arrow win appear.
6. If you want to change the current display mode, move the arrow by pressing POINT UP/OOWN butte
the item of the mode that you want to change into.
7. Press the SELECT button to change the display mode.
8. To quit the Computer System Menu, move the arrow to Quit and then press SELECT button.
COMPUTER SYSTEM SELECT (COMPUTER MODE)
■ti..
CameuBir
•r-'
T SY^ror
MAIN MENU DISPLAY
S I li^r !8!!rH^SsP>lLa
COMPUTER
SYSTEM
DISPLAY
V3A2-.
.VgA3~
VOA4-
( Quit }
CURRENT
MODE
DISPLAY
Current mode
H-Synefreq. I 36.5
I
V-Synefreq.. I 60.0~i
*VGA1- -
ÍÍGA2:*
5teA3 '
“YSr::
VOA4-
“ •
Model
- 4»
VGA2
.VQA3
VGA4
Mode 1
Mode2
[ Quit )
When the mark (O ) is displayed as BLACK,
computer system mode will be available on the
next page. Move an arrow to the mark (O )
and press SELECT button to show computer
system mode desenbed on the next page.
PC ADJUSTMENT
This is a special function that may be used when a computer image is not reproduced property. (See the
f
36- 39 for more detail.)
