CONNOTING THE VIDEO EQUIPMENT
CONNECTING TO THE AUDIO/VIDEO INPUT JACKS
Connectng to the video and audio outputs ot a VCR. video disc player, video camera, satellite
TV tuner or other Video equipment
• Connect audkVvideo outputs from external source to these input jacks using the
audioA/ideo cable.
• If the audio signal from the Video equipment is stereo, be sure to connect the right and left
channels to the respective right and left audio input jacks.
• If the external audio signal is monaural, connect it to the L (MONO).
S»VHS FORMAT VCR CONNECTION
The Video input includes an extra video input jack marked S-VIDEO to aJkiw connection to an
S-VHS format VCR that has separate Y/C video sigrtals. The S-Vl^O jack has priority over
the VIDEO jack.
1
CONNECTING THE EXTERNAL AUDIO EQUIPMENT
CONNECTING TO THE AUDIO OUT JACK (mini stereo type)
This jack outputs stereo sound from video or computer mput when viewit>g on screen. If you
use external audio equipment, connect an audio anrtpifier. Internal speaker sound is retained
when AUDIO OUT jack is connected.
Video and External Audio Equipments connection
Connect equipments referring trie figure betow.
VIDEO EQUIPMENT
’
I Video Cassette Recorder
VWeo Oise Player
sateNrte
ii
I
TV Tuner
L
— IS —
