Appendix 5 — Exploded Views and Parts Lists
^PARTS
LISTS
QUIETPACT™ 75D Recreational Vehicle Generator
1.0 Liter Diesel Engine Block - Drawing No. 82961-A
29
ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION
1 139-70939 1 OIL PAN 19 185-70939 1 OIL STOPPER
2 140-70939 20 BOLT 20 186-70939 1 SCREEN
12 143-70939 1 DIPSTICK TUBE 22 168-70939 1 GASKET
(ALL MODELS EXCEPT 04270) 23 187-70939 3 NUT
C4641 1 DIPSTICK TUBE 24 188-70939 1 CAP
(MODEL 04270 ONLY) 25 189-70939 1 O-RING
13 144-70939 2 O-RING 28 26073-A 1 1/4" PIPE PLUG SO. HD,
14 145-70939 5 BOLT 29 244-70939 1 O-RING
15 146-70939 1 DIPSTICK 30 245-70939 1 TUBING
(ALL MODELS EXCEPT 04270) 31 246-70939 1 SUCTION FILTER
17 183-70939 1 ROCKER COVER GASKET 33 122-70939 1 GASKET
18 184-70939 1 ROCKER COVER
