INSTALLATION
Section 2 - Installation
QUIETPACT™ 75D Recreational Vehicle Generator
Seams and joints of the galvanized steel (whether
used as a liner or for the compartment itself) must
be lapped and mechanically secured. Such seams
may be manufactured, welded, bolted, riveted or
screwed. Manufactured lock seams are shown in
Figure 2.4. Installer constructed compartments
typically utilize a standard lap joint.
Figure 2.4 - Types of Lock Seams
DANGER
FOUI
DOUBLE LOCK
OFFSET
DOUBU SEAM
IL W p
LOCKED STANDING
I I
* ■ OFF SI
r
ACME LOCK
GORDON SEAM LOCK SEAM
STANDARD UP JOINT
After the compartment has been metal lined and
vapor sealed, line the compartment interior walls
and ceiling with an approved, nonflammable
sound insulating material. See Section 2.2.2.
A
DANGER
Do not install any flammable material directly
above or around the compartment. Heat,
transferred through the compartment structure,
may be sufficient to ignite, char or discolor
seat cushions, fiberboard and other flammable
materials. You may need to use approved
nonflammable insulating materials in high
temperature areas.
♦ 2.2.2 SOUND INSULATING MATERIALS
Once installers have determined that a compartment
is properly constructed and metal lined, they can add
acoustical material. This may include additional
sealant or insulating material, to reflect noise away
from the vehicle interior.
Sound insulating materials should be of a nonflam­
mable type. One excellent insulating material is a 1-
inch (25 mm) thick fiberglass having a 2-pound den­
sity. When fiberglass is used, its coated side should
face toward the compartnyent interior.
A Do not install sound insulation or any
absorbent material on the compartment floor
interior. Such materials will become soaked
with combustible or explosive vapors and
liquids and will become a fire hazard.
Using a combination of sound insulating materials
can often reduce noise more effectively than a sin­
gle material. For example, a sheet of lead or visco­
elastic material, along with a layer of other acousti­
cal material, is more effective than when a single
material is used.
♦ 2.2.3 ACOUSTICS______________________________
For additional noise abatement, the installer may
wish to consider the following:
• Using special sound insulating materials.
•
Construction of a special noise abatement
compartment.
NOTE:
Any method used to reduce noise must not
adversely affect the flow of cooling and ventilating
air into or out of the compartment.
In addition to the effective use of sound insulating
materials, construction of a special noise abatement
compartment might be considered to reduce noise
levels. Such a compartment might be constructed as
follows (Figure 2.5, Page 25):
• Use 5/8-inch thick or 3/4-inch thick plywood in the
compartment.
• Construct the compartment floor of a double thick­
ness of 5/8-inch or 3/4-inch plywood.
• Line the compartment interior walls and floor, as
well as the underside of the floor, with 26-gauge
galvanized steel.
• Vapor seal all compartment seams and joints.
• Over the galvanized steel lining, install a combina­
tion of acoustical materials as mentioned in
Section 2.2.2.
DANGER
gk To prevent fire or explosion, do not install any
insulation or other absorbent materials on the
interior or underside of the compartment floor.
Seal all compartment door edges to prevent noise
leakage around the door perimeter.
Line the compartment door interior (except for air
openings) with suitable, fireproof sound insulation
(such as 1-inch (25 mm) thick fiberglass with a 2-
pound density).
