MODEL 829003 36 ST SNOW THROWER ATTACHMENT
REF
NO.
PART
NO.
DESCRIPTION
CO
o
o
O)
CM
eo
REF
NO
PART
NO
DESCRIPTION
CO
o
s
CM
eo
1
529011
AUGER HOUSING W/Oecal
1
37
029250
CHAIN
1
2
029223
AUGER
1
38
029237
SUPPORT
1
3
054111
BEARING
2
39
062028
CARRIAGE BOLT, 3/8-16x1"
2
4
064009
WASHER, Flat, 3/4"
AR
40
065023
WING NUT, 3/8-16
2
5
029224
MOUNTING PLATE
2
41
029239
BAR
2
6
059154
CAP SCREW, 3/8-16
X
3/4, H.H. Gr. 5
8
42
029240
SHEAVE
1
7
063021
LOCKWASHER,3/8"
19
43
059160
CAPSCREW, 3/8-16
X
2-3/4" H.H. Gr. 5
1
8
029225
SKIOSHOE
2
44
029241
WEAR PLATE
1
! 9
062010
CARRIAGE BOLT, 3/8-16x3/4"
7
45
062011
CARRIAGE BOLT, 5/16-18 x 3/4
6
10
064008
WASHER, Flat, 3/8"
16
46
029242
BRACKET
1
11
065018
NUT, Hex, 3/8-16
16
47
029161
SPACER BUSHING
1
1 12
029226
SHROUD
1
48
059145
CAP SCREW, 3/8-16
X
1" H.H. Gr. 5
1
1
529040
DEFLECTOR W/Dacal
1
49
073066
IDLER
1
1
059155
CAP SCREW, 1/4-20 x 1/2" H.H. Gr. 5
2
50
059143
CAP SCREW, 1/2-13
X
2-1/4, H.H. Gr. 5
1
t
is
065070
LOCKNUT, Crown, 1/4-20
2
51
064003
WASHER, Flat, 1/2"
2
1 16
029229
LOCKING LEVER
2
52
063006
LOCKWASHER, 1/2"
1
1
17
064147
WASHER, Special
2
53
065021
NUT, Hex, 1/2-13
1
^18
029228
SPOUT RING HOLDER
3
54
083127
EXTENSION SPRING
1
062034
CARRIAGE BOLT, 5/16-18 x 3/4"
7
55
029244
SHEAVE
1
063003
LOCKWASHER, 5/16"
15
56
059161
CAPSCREW, 3/8-16
X
1-3/4, H.H. Gr. 5
1
1 21
065015
NUT, Hex, 5/16-18
17
57
029245
SPACER
1
: 22
029230
DISC CONTROL COIL
1
58
072104
"V" BELT
1
23
083142
COMPRESSION SPRING
1
59
029221
SHEAVE
1
24
029231
SPLIT SPACER
1
60
029246
BRACKET
2
; 25
029232
BRACKET
1
61
059133
CAPSCREW, 3/8-16
X
1-1/4, H.H. Gr. 5
2
26
031268
UNI VERBAL,BLOCK JOINT
1
62
083107
SPRING
2
27
029238
CHUTE CONTROL HANDLE
1
63
029247
COVER
1
28
067001
PIN, Cotter, 3/32 x 3/4
2
64
070015
FLANGE WHIZLOCK SCREW,
6
29
067029
HAIRPIN COTTER
3
1/4-20x1/2
: 30
029234
SHAFT
1
65
029190
TUBE
1
^ 31
054112
BEARING
2
66
029189
SPLIT SPACER
1
. 32
054113
FLANGETTE
4
67
059151
CAPSCREW, 3/8-16
X
1-1/2, H.H. Gr. 5
1
; 33
029235
SPROCKET W/Setscrew
1
68
078271
DECAL, Caution
1
; 34
060012
SETSCREW, 5/16-18x3/8 Nylok
6
69
078244
SPRIPT NAME PLATE
1
: 35
066003
KEY, Woodruff No. 9
2
70
078298
DECAL, Warning
1
36
029236
TUBE
1
71
059128
CAPSCREW, 5/16-18 x 1-3/4, H.H. Gr. 5
2
72
064002
WASHER, Flat, 5/16"
4
