FRONT BLADE - 42FB - 829002
LAME 42FB -829002
NoDE
REF.
REF.
N0.
NO DECODE
PIECÉ D'INV
PART
STOCK
NO. CODE
QUANTITÉ
DESCRIPTION
NO. REQ'D
829002
1
029180
0
FRAME
1
2
029181
0
SUPPORT
1
3
029184
S
ROD
1
4
062033
M
CAPPING BOLT, 5/16" -18 x 3/4"
1
5
031254
M
LATCH PIN
1
6
083132
M
SPRING
1
7
029185
0
BLADE
1
8
029186
s
WEAR PLATE
1
9
029187
s
ROD
1
10
031271
M ,
SKIDSHOE
2
11
083133
M
SPRING
2
12
029190
s
TUBE
1
13
029189
s
SPACER
1
14
067029
M
HAIRPIN COTTER
1
15
065012
M
WING NUT, 1/4"-20
2
16
029188
0
BRACE
1
17
031252
s
PIVOT PLATE
1
18
031275
s
ROD
1
19
031269
s
ANGLE
1
20
029182
s
ROD
1
21
029183
s
STRAP
1
22
029191
0
SUPPORT
1
23
031268
s
BLOCK JOINT
1
24
067026
M
PIN, Cotter, 3/16" x1"
4
25
059069
M
CAPSCREW, HH, 5/16" ■ 18
X
1-1/4"
1
26
064002
M
WASHER, Flat, 5/16"
7
27
065101
M
LOCKNUT, Hex, 5/16"-18
2
28
062015
M
CARRIAGE BOLT, 5/16" - 18 x 1"'
7
29
063003
M
L0CKWASHER,5/16"
7
30
065015
M
NUT, Hex, 5/16"-18
7
31
062029
M
BOLT, Carriage, 3/8"- 16x1"
4
32
064008
M
WASHER, Flat, 3/8"
9
33
063021
M
LOCKWASHER,3/8"
8
34
065018
M
NUT, Hex, 3/8"-16
8
35
059006
M
CAPSCREW, 3/8"-16"
X
1-1/2"
1
36
059154
M
CAP SCREW, 3/8"- 16x1" Grade 5
2
37
029140
M
SPACER
1
38
067024
M
PIN, Cotter, 1/8"
X
3/4"
5
39
067004
M
PIN, Cotter, 1/8"
X
1"
1
40
059004
M
CAP SCREW, 3/8"- 16x1"
1
41
062037
M
CARRIAGE BOLT, 1/4"-20x1"
2
42
063002
M
LOCKWASHER, 1/4" Std.
2
078144
0
ARIENS SCRIPT DECAL (Not III.)
1
SUGGESTED PARTS STOCKING CODE
F - FAST
S - SLOW
M - MEDIUM
O - CUSTOMER ORDER ONLY
CODE SUGGÉRÉ D'INVENTAIRE DES PIÈCES
F - FAST (rapide)
S - SLOW (lent)
M — MEDIUM (moyen) 0 — Commande du client seulement
PAGE 25
