Ariens 929000 - Manual (Page 37)

SHIFT CONTROL & LINKAGE -HYDROSTATIC
»
REF
NO.
PART
NO.
DESCRIPTION
CM
o
o
O)
CM
O)
REF
N0.
PART
NO.
DESCRIPTION
CM
o
o
O)
CM
1 029061 SHIFT LEVER 1 28 064009 WASHER, Flat, 3/4" 2
2 075049 HANDLE 1 29 058019 PIN, Grooved, 3/16" x 1 Type E 1
3 083112 SPRING, Tension 1 30 058049 PIN, Grooved, 3/16" X 1-1/4"
4 029055 PIVOT ASS'Y 1 Type E 1
5 029062 BRACKET 1 31 022093 FITTING, Grease, 1/4"-28 1
6 029057 LINK 1 32 059023 CAPSCREW, HH, 3/8"-16x3/4" 1
7 029053 NEUTRALIZER 1 33 064008 WASHER, Flat, 3/8" 7
8 064117 SHIM, 005 Thick 2 34 063021 LOCKWASHER,3/8" 9
9 064118 SHIM, 010 Thick 1 35 059003 CAP SCREW, HH, 5/16"- 18x1" 2
10 064119 SHIM, 025 Thick 3 36 064002 WASHER, Flat, 5/16" 4
11 064108 SHIM, Washer 2 37 063003 LOCKWASHER, 5/16" 5
12 029064 ARM 1 38 065015 NUT, Hex, 5/16"-18 5
13 029159 SPACER 2 39 067024 PIN, Cotter, 1/8"
X
3/4" 1
14 029056 PLATE 2 40 059005 CAPSCREW, HH, 3/8"-16 X 1-1/4" 2
15 055080 BUSHING 4 41 065018 NUT, Hex, 3/8"-16 8
16 029066 ROLLER 3 42 059073 CAPSCREW, HH, 5/16"-18 X
17 029065 ■SPACER 3 1-3/4" 1
18 029052 CAM 1 43 066006 KEY, Woodruff, No. 3 1
19 029063 PLATE 1 44 059027 CAPSCREW, HH, 3/8"- 16 x
20 029060 LEVER 1 1-3/4" 1
21 029160 WASHER, Spacer 1 45 065098 LOCKNUT, Hex, 3/8"-16 2
22 029068 SPACER 1 46 062011 BOLT, Carriage, 5/16" -18 X
23 029054 LEVER 1 1-3/4" 2
24 629033 FRONT DRAG BRKT. 1 47 062030 BOLT, Carriage, 1/4" - 20 x 3-1/2" 1
25 059004 CAPSCREW, HH,3/8"- 16x 1" 4 48 064007 WASHER, Flat, 1/4" 1
26 629032 REAR DRAG BRKT. 1 49 065070 LOCKNUT, Hex, 1/4"-20 1
27 083115 SPRING 1 50 029220 LINING 2
51 068053 RIVET 4
►
PAGE 37
