HAND LIFT & SHEAVE
RELEVAGE MANUEL - POULIE
NoDE NO DE CODE
REF. PIECÉ D'INV
REF. PART STOCK
NO. NO. CODE
DESCRIPTION
QUANTITÉ
NO. REQ'D
929001 929002
1 029082 S LIFT LEVER 1 1
2 029Ù83 S ROD 1 1
3 083104 S SPRING 1 1
4 064096 M WASHER, Special 1 1
5 075053 M GRIP 1 1
6 029084 s BRACKET 1 1
7 029090 s LIFT PLATE 1 1
8 055082 F BUSHING, Nylon 2 2
9 064097 M WASHER, Special 1 1
10 029091 S STRIP 1 1
11 029088
s LIFT 1 1
12 029141 M SPACER 2 2
13 029092 s LINK 1 1
14 029096 M PIN 1 1
15 029093 M LINK, R.H. 1 1
16 029094 M, LINK, L.H. 1 1
17 55089 M BUSHING 8 8
18 029095 M LINK 2 2
19 029085 s SHEAVE 1 1
20 64088 M WASHER 2 2
21 029089 s BEARING HOUSING 1 1
22 054073 M BALLBEARING 2 2
23 029086 M SHEAVE, PTO 1 1
24 064108 M WASHER, Special (AR) (AR)
25 057012 M SNAP RING 1 1
26 029087 M BELT GUIDE 1 1
27 058034 M ROLL PIN, 1/8" X 3/4" 1 1
28 062029 M BOLT, Carriage 3/8"- 16 x 1" 4 4
29 064008 M WASHER, Flat, 3/8" 14 14
30 063021 M
L0CKWASHER,3/8" 14 14
31 065018
M
NUT, Hex, 3/8"-16 14 14
32 067004 M PIN, Cotter, 1/8" x1" 6 6
33 062016
M
BOLT, Carriage, 3/8" ■ 16 x 1-1/4" 2 2
34 059Û04 M
CAPSCREW, HH, 3/8"- 16 x 1" 4 4
35 059005
M CAP SCREW, HH, 3/8" X 16 x
1-1/4" 4 4
36 066003
M KEY, Woodruff, No. 9 1 1
37 059003
M
CAPSCREW, HH, 5/16"- 18x1" 2 2
38 064002
M
WASHER, Flat, 5/16" 3 3
39 063003
M
LOCKWASHER,5/16" 3 3
40 065015 M
NUT, Hex, 5/16"-18 2 2
41 058050 M
PIN,Groove, 1/4" X 1-1/4"
Type E 1 1
42 059039 M
CAPSCREW 5/16"-18 X 1/2 1 1
43 069094 M J-CLAMP 1 1
SUGGESTED PARTS STOCKING CODE
F - FAST S -SLOW
M - MEDIUM 0 - CUSTOMER ORDER ONLY
PAGE 15
CODE SUGGÉRÉ D'INVENTAIRE DES PIÈCES
F - FAST (rapide) S - SLOW (lent)
M — MEDIUM (moyen) O — Commande du client seulement
