13. HOWTO ADJUST THE STITCH
LENGTH
The stitch length dial should be set on the 3 mm
(1/8 inch) setting for most sewing conditions.
Adjust the stitch length to 4mm (5/32 inch) when
sewing heavy weight fabrics.
Adjust the stitch length to 2mm (5/64 inch) when
sewing light weight fabrics to obtain excellent
seams without puckering.
14. HOWTO ADJUST THE SEAM
WIDTH
• Overedge seam width can be achieved by
repositioning the needle position and also with
the width adjustment knob.
Width Adjustment by Changing Needle Position
• Overedge seam width can be adjusted by changing
the needle position.
a) When only left needle is used........................5.7 mm
(7/32 inch)
b) When only right needle is used...................... 3.5 mm
(9/64 inch)
Width Adjustment with Adjustment Knob
Use of width adjustment knob will permit further
adjustment within the width range shown beiow.
a) When only left needle is used.............. 5.2 •*' 6.7 mm
(13/64 ~ 17/64 inch)
b) When only right needle Is used ... 3.0 ~ 4.5 mm
(1/8-11/64 inch)
ncer
KAiOcK
c 3
ÍÍ
Left/Right
needle
Aguja izquierda/
derecha
Gauche/
droite aiguilie
Left needle
Aguja izquierda
Gauche aiguilie
Aguja derecha
Droite aiguiile
5.2 mm 5.2 mm 3.0 mm
(13/64") (13/64") (1/8")
6.7 mm
Âll\
6.7 mm 4.5 mm
i A A t C A ll\ t
Left needie Left/Right
needle
Aguja izquierda
Gauche/
droite aiguille Gauche aiguille
Right needle
Aguja derecha
Droite aiguille
