Before moving selectors, make sure needle is
out of the fabric
How to set selectors for straight
stitching
• Needle Position:
• Stitch Width: 0
• Stitch Length: .5 - 4 to suit fabric
How to set selectors for zig-zag
stitching
• Pattern Group Selector: 1-2-3-4-5
• Needle Position:
L ______ I
• Stitch Width;
1
to
6
• Stitch Length: .5 - 4 to suit fabric
1. STITCH WIDTH SELECTOR
To produce a plain zig-zag or a decorative
stitch, the stitch width selector is moved from
its straight stitch position
0
to any of its other
five positions. The further you move the
selector lever toward the right, the wider your
stitch will be.
6 7
8 9
» 'Vvx
10
11
1-2-3-4-5
2. NEEDLE POSITION SELECTOR
Most of your zig-zag stitching will be done in
centre M needle position.
Left ui and right » setting are used for
special stitch placement, as in button sewing.
3. PATTERN GROUP SELECTOR
For plain zig-zag stitching:
• Set stitch width selector on 0 (straight
•
stitch)
• Turn pattern group selector to 1-2-3-4-5
aligning number under • mark.
