background image

62

Object

Index Range Restrictions

Proportional Band-( VT72xx & VT73xx )

1

2 ºF / 1.1 ºC

2

3 ºF / 1.7 ºC

3

4 ºF / 2.2 ºC

4

5 ºF / 2.8 ºC

5

6 ºF / 3.3 ºC

6

7 ºF / 3.9 ºC

7

8 ºF / 4.4 ºC

Pulsed Heat

1

On

2

Off

3

Occupancy Output

RUI1 Config

1

None

2

Filter

3

Service

4

(COC/NH) Change over dry contact.
Normally Heat

5

(COC/NC) Change over dry contact.
Normally Cool

6

(COS) Change over analog sensor

RBI2 Config

1

None

2

Filter

3

Service

Reheat Config

1

None

2

Analogue Duct Heater Only

3

On/Off Duct Heater Only

4

On/Off Peripheral Heating Only

5

Analogue Duct and On/Off Peripheral
Heating

Reheat CPH

1

2 CPH

2

3 CPH

3

4 CPH

4

5 CPH

5

6 CPH

6

7 CPH

7

8 CPH

Zone Sequence

1

Cool

2

Heat

Sequence Of Operation ( VT73xx & VT72xx )
Note 2

1

Cooling only

2

Heating only

3

Cooling & reheat

4

Heating & reheat

5

Cooling & heating 4 pipes

6

Cooling heating 4 pipes & reheat
