56
Object Name Object Type Thermostat Range / Indexes
Low Battery Alarm Boolean Point falseText=Off,trueText=On
Mechanical Cooling Enable Boolean Writable falseText=Off,trueText=On
Menu Scroll Boolean Writable falseText=No Scroll,trueText=Scroll Active
Outdoor Temperature Override Boolean Writable falseText=Normal,trueText=Override
PIR Motion Status Boolean Point falseText=No Motion,trueText=Motion
Progressive Recovery Boolean Writable falseText=Off,trueText=Active
RBI2 Status Boolean Point falseText=Off,trueText=On
Reheat Time Base Boolean Writable falseText=15 Minutes,trueText=10 Seconds
Reversing Valve Config Boolean Writable falseText=Normally Cool,trueText=Normally Heat
Reversing Valve Status Boolean Point falseText=Off,trueText=On
RH Display Boolean Writable falseText=Disabled,trueText=Enabled
Room Humidity Override Boolean Writable falseText=Normal,trueText=Override
Room Temperature Override Boolean Writable falseText=Normal,trueText=Override
RTC Smart Recovery Active Boolean Point falseText=Off,trueText=On
RUI1 Status Boolean Point temperature,min=-40,max=122
Service Alarm Boolean Point falseText=Off,trueText=On
Set Clock Alarm Boolean Point falseText=Off,trueText=On
Setpoint Function Boolean Writable falseText=Dual Setpoints,trueText=Attached Setpoints
Setpoint Type Boolean Writable falseText=Permanent,trueText=Temporary
Supply Heat Lockout Status Boolean Point falseText=Inactive,trueText=Active
Supply Heat Lockout Status Boolean Point falseText=Inactive,trueText=Active
UI3 Status Boolean Point falseText=Deactivated,trueText=Activated
Units Boolean Writable falseText=Imperial,trueText=SI
W1 Status Boolean Point falseText=Off,trueText=On
W2 Status Boolean Point falseText=Off,trueText=On
Window Alarm Boolean Point falseText=Off,trueText=On
Wireless Door Switch Status Boolean Point falseText=Off,trueText=On
Wireless Door Switch Used Boolean Point falseText=Not Used,trueText=Used
Wireless Window Switch Status Boolean Point falseText=Off,trueText=On
Wireless Window Switch Used Boolean Point falseText=Not Used,trueText=Used
Y1 Status Boolean Point falseText=Off,trueText=On
Y2 Status Boolean Point falseText=Off,trueText=On
* This object is linked to UI3 input on all VT7200 and VT7300 series controller when used in binary mode. The
Not Activated / Activated flag status is changed upon a local contact closing on the input and will also result in
the SupplyTemp Numeric to respond from one end of its range to the other.
