List of Property Numeric Value Range Restrictions
Please refer to the specific installation guide of each controller for a detailed overview on each property listed
Object Name Object Type Thermostat Range / Indexes
AI1 Value Numeric Point volt,min=0,max=10
Analog Heat Output Status Numeric Point percent,min=0,max=100
AO2 Outside Air Lockout Setpoint Numeric Writable temperature,min=-40,max=122
AO2 Status Numeric Point percent,min=0,max=100
BO5 Outside Air Lockout Setpoint Numeric Writable temperature,min=-40,max=122
ByPass Damper Position Numeric Point percent,min=0,max=100
ByPass Damper Position Or VFD Numeric Point percent,min=0,max=100
CO2 Level Numeric Point parts per million,min=0,max=2000
Cooling Demand Limit Numeric Writable percent,min=0,max=100
Cooling Lockout Temperature Numeric Writable temperature,min=-40,max=95
Cooling Setpoint Limit Numeric Writable temperature,min=54,max=100
Damper Max Heat Position Numeric Writable percent,min=0,max=100
Damper Maximum Position Numeric Writable percent,min=0,max=100
Damper Minimum Position Numeric Writable percent,min=0,max=100
Damper Position Numeric Point percent,min=0,max=100
Deadband Numeric Writable temperature,min=2.0,max=4.0
Deadband Numeric Writable temperature,min=2.0,max=5.0
Dehumidification Hysteresis Numeric Writable percent,min=2,max=20
Dehumidification Low OA Lockout Numeric Writable temperature,min=-40,max=122
Dehumidification Max Cooling Numeric Writable percent,min=20,max=100
Dehumidification RH Setpoint Numeric Writable percent,min=15,max=95
Dehumidification RH Setpoint Numeric Writable percent,min=30,max=95
Discharge High Limit Setpoint Numeric Writable temperature,min=70,max=150
Discharge Low Limit Setpoint Numeric Writable temperature,min=35,max=65
Economizer Changeover Setpoint Numeric Writable temperature,min=14,max=70
Economizer Maximum Position Numeric Writable percent,min=0,max=100
Economizer Minimum Position Numeric Writable percent,min=0,max=100
Economizer Output Numeric Point percent,min=0,max=100
Effective Humidification RH Setpoint Numeric Point percent,min=0,max=100
Fresh Air Level Numeric Point cubic feet per minute,min=0,max=20000
Fresh Air Max Range Numeric Writable cubic feet per minute,min=0,max=20000
Get From Numeric Writable none,min=0,max=254
Heating Demand Limit Numeric Writable percent,min=0,max=100
Heating Lockout Temperature Numeric Writable temperature,min=-15,max=120
Heating Setpoint Limit Numeric Writable temperature,min=40,max=90
High Balance Point Numeric Writable temperature,min=34,max=90
High Temperature Reset RH Setpoint Numeric Writable temperature,min=20,max=55
Humidification High Limit Setpoint Numeric Writable percent,min=50,max=90
Humidification RH Setpoint Numeric Writable percent,min=10,max=90
Humidifier Output Numeric Point percent,min=0,max=100
Low Balance Point Numeric Writable temperature,min=-40,max=30
Low RH Setpoint Numeric Writable percent,min=10,max=90
Low Temperature Reset RH Setpoint Numeric Writable temperature,min=-40,max=15
Maximum CO2 Level Numeric Writable parts per million,min=0,max=2000
Maximum Fresh Air Numeric Writable cubic feet per minute,min=0,max=20000
Minimum CO2 Level Numeric Writable parts per million,min=0,max=2000
Minimum Fresh Air Numeric Writable cubic feet per minute,min=0,max=20000
