58

Object

Index Range Restrictions

Aux Configuration

1

Not Used

2

Normally Opened With Occupancy

3

Normally Closed With Occupancy

4

Normally Opened With Occupancy & Fan

5

Normally Closed With Occupancy & Fan

6

Network Controlled

Cooling CPH

1

3 CPH

2

4 CPH

Control Type

1

Highest

2

Average of 3 highest

3

Average of 5 highest

BI1 Config ( VT72 / VT73xx )

1

None

2

Rem NSB

3

Motion NO

4

Motion NC

5

Window

BI2 Config ( VT72 / VT73xx )

1

None

2

Door Dry

3

Rem OVR

4

Filter

5

Service

DI1 Config ( VT76xx )

1

None

2

Rem NSB

3

Rem OVR

4

Filter

5

Service

6

Fan Lock Alarm

DI2 Config ( VT76xx )

1

None

2

Rem NSB

3

Rem OVR

4

Filter

5

Service

6

Fan Lock Alarm
