SETPOINT SETTINGS
Configuration parameters
default value
Significance and adjustments
Unocc. cool.
Default value = 26.5 °C
( 80 °F ) Unoccupied cooling setpoint range is:
12.0 to 37.5 °C ( 54 to 100 °F )
Standby cool.
Default value = 25.5 °C
(78 °F ) Standby cooling setpoint. The value of this parameter should be set
between the occupied and unoccupied cooling setpoints. Make sure that
the difference between the stand-by and occupied value can be recovered
in a timely fashion when movement is detected in the zone.
Stand-by cooling setpoint range is: 12.0 to 37.5 °C ( 54 to 100 °F ).
Occ. cool.
Default value = 24.0 °C
( 74 °F ) Cooling setpoint range is:
12.0 to 37.5 °C ( 54 to 100 °F ).
Occ. heat.
Default value = 22.0 °C
( 72 °F ) Heatling setpoint range is:
12.0 to 37.5 °C ( 54 to 100 °F ).
Standby heat.
Default value = 20.5 °C
( 69 °F ) Stand-by heating setpoint. The value of this parameter should be set
between the occupied and unoccupied heating setpoints. Make sure that
the difference between the stand-by and occupied value can be recovered
in a timely fashion when movement is detected in the zone.
Stand-by heating setpoint range is: 4.5 to 32.0 °C ( 40 to 90 °F ).
Unocc. heat.
Default value = 16.5 °C
( 62 °F ) Unoccupied heating setpoint range is:
4.5 to 32.0 °C ( 40 to 90 °F ).
PARAMETER DETAILS
1/2 Setpoints
Occ. cool.
Standby cool.
Unocc. cool.
25.5 °C
24.0 °C
22.0 °C
20.5 °C
16.5 °C
26.5 °C
Occ. heat.
Standby heat.
Unocc. heat.
