5
ANGLE OFF /ON/1s/3s/5s/10s
Displays the coordinate. Pan (0 to 359°)/ Tilt (5 to -185°) fixed 8 characters.
[ ***/-*** ] Pan angle (0 to 359°)/ ±Tilt (5 to 185°)
ZOOM OFF /ON/1s/3s/5s/10s Displays the Electronic Zoom. Fixed 3-charactors.
DATE OFF /ON/1s/3s/5s/10s
Displays the date in accordance with the date setting (timer setting) format.
Fixed 8-charactors.
TIME OFF /ON/1s/3s/5s/10s
Displays the time in accordance with the time (hour, minute) setting (timer
setting) format. (Format: fixed 5 or 7-charactors)
ID SETTING
CAMERA
POSITION ***POS 1-255
TRACE TRACE 1-2
AUTO PAN
TOUR TOUR 1-16
HOME HOME 1-3
ALARM ALARM 1-8
The ID setting screen is displayed.
Input the title character.
SECTOR
SECTOR SETTING/ID
SETTING
1)SECTOR SETTING FIX/EACH/CLEAR 1-8
2) ID SETTING SECTOR 1-8
The range of the sector is set or is cleared.
The sector title is set.
Setting North permits the direction to be automatically divided into 8 sectors.
(north, north east, east, south east, south, south west, west, and north west)
AUX AUX 1-2 The ID setting screen is displayed. Input the title character.
LOCATION
ADDRESS LOCATION SETTING
CAMERA
POSITION
TOUR
LOCATION SETTING/
LENGTH SETTING
HOME
LOCATION SETTING/
LENGTH SETTING - HOME1-3
ALARM
SECTOR
AUX
LOCATION SETTING/
LENGTH SETTING
ANGLE DISP
ZOOM DISP
DATE DISP
TIME DISP
LOCATION SETTING
Setting title display position and its length.
PATTERN CLEAR NO /YES
All set display positions and lengths can be reset to initial factory-preset
conditions.
FRAME ADJUST Adjust the character display position.
ZERO POINT Change the origin point of the angle (Zero point) display.
CAMERA SETTING (CAM)
WHITE BALANCE ATW /AWB
The white balance may be set to either AWB or ATW. (factory default: ATW)
ATW : The camera adjusts its white balance setting according to fluctuations in
the color temperature of the subject’s illumination.
AWB : The camera uses a fixed white balance setting regardless of fluctuations in
the color temperature of the subject’s illumination.
