4
Commands Keystrokes Description
PRESET
MEMORY POS 1-255 - FINE SETTING
Settings such as camera direction, lens angular field of view, and focus can
be preset in advance. Up to 255 positions can be set.
READJUST ALL POS POS 1-255
This function simultaneously resets all preset camera panning positions.
The deviation of one camera position is measured, based on which all other
positions are globally corrected. When performing this global correction, use
the position on the telescope side whenever possible.
MEMORY RESET POS 1-255 The stored position is erased.
MEMORY ALL RESET NO /YES Deletes all preset position data.
AUTO RETURN
OFF /5s/10s/15s/20s/30s/45s/
1min/3min/5min
This function is used to determine operation when the camera is not
controlled at all. The camera automatically reverts to the initially set program
when the preset period of time elapses after the controller’s control has been
finished.
HOME
1POS /2POS/254POS/255POS/
AUTO PAN/SEQUENCE/
TRACE1-2/TOUR1-16 Designate the program the camera automatically returns to.
PRESET FREEZE (*1) OFF /ON
Freezing the screen immediately before replaying preset memory blanks
out the view of the camera’s movement between camera positions. It is
recommended that the preset memory freeze function also be used
together when using the privacy masking function.
ID SETTING
DISPLAY
ALL
INDIVIDUAL /1s/3s/5s/10s/
OFF/ON
Contents or time to be displayed can be set by selecting “Display” on the ID
setting screen.
OFF : Nothing is displayed.
ON : Every ID are all displayed.
1s, 3s, 5s, 10s : ID is displayed for a set length of time.
INDIVIDUAL : Performs display settings for each ID.
ADDRESS OFF /ON/1s/3s/5s/10s
Displays the camera address and camera position No. Title length can be
freely adjusted from 3 to 7 digits.
(Camera address: DIP SW1: for setting, factory-preset: 001)
[ ***-*** ] Camera address - Position number
CAMERA OFF /ON/1s/3s/5s/10s Displays the Camera Title.
POSITION OFF /ON/1s/3s/5s/10s Displays the Position title (1 – 255).
TRACE OFF /ON/1s/3s/5s/10s Displays the Trace title (1 – 2).
AUTO PAN OFF /ON/1s/3s/5s/10s Displays the Auto-Pan title.
TOUR OFF /ON/1s/3s/5s/10s Displays the Tour title (1 – 16).
HOME OFF /ON/1s/3s/5s/10s Displays the Home Position title (1 – 3). Up to 3 titles can be set.
ALARM OFF /ON/1s/3s/5s/10s Displays the Alarm title (1 – 8).
SECTOR OFF /ON/1s/3s/5s/10s Displays the title for the sectors split in the panning direction.
AUX OFF /ON/1s/3s/5s/10s Displays the AUX contact output title (1 – 2).
FUNCTION TABLE
