10
SEQUENCE
The Preset Sequence function displays set positions of one same camera
on the monitor in predetermined sequential order.
MODE NORMAL /RANDOM/TEST
Sets the sequence order. (factory default: Normal)
NORMAL: Playbacks preset-memory stored camera positions in numerical
order.
RANDOM: Playbacks preset memory store camera positions in random order.
The stop duration for each position is determined in random order.
TEST : Playbacks preset-memory stored camera positions in numerical
order. The stop time for each position is set to 1 second and the
sequence will be terminated after making a position circuit.
STOP TIME 10s /20s/30s/1s/2s/3s/5s
Set the interval of sequential playback duration.
(Factory default: 10s)
TRACE
TRACE1 /TRACE2/CLEAR1/
CLEAR2
The Trace function follows a set path.
TRACE1 PAUSE TIME
TRACE2 PAUSE TIME
1s /2s/3s/5s/10s/20s/30s
When continuously playing back the trace operations with the Auto key (or
Auto-Pan key), the stop duration interval between start position and end
position of one trace operations can be set. (Factory default: 1s)
TOUR Tour function can be operated in combination of Preset, Trace, etc.
ORDER number 1-16 Set the operation to be programmed to each Tour Nos. 1 – 16.
Choice Selected contents 1 Selected contents 2
***POS
SP360/SPA/SP8/SP16/SP24/
SP40/SP60/SP90/SP120/SP160/
SP240
10s/20s/30s/1s/2s/3s/5s
AUX1 ON/AUX1 OFF/
AUX2 ON/AUX2 OFF
– –
TOUR 1 - 16
1TIME/2TIME/3TIME/4TIME/
5TIME
–
TRACE 1 - 2
1TIME/2TIME/3TIME/4TIME/
5TIME
–
B/W ON / B/W OFF – –
STOP – –
INSERT Inserting operation into Tour program.
RESET Deleting Tour Program.
ALARM
INPUT number 1-8: OFF /ON
Of alarm inputs, designate the input number to which an alarm signal is
actually connected. Unless the alarm input settings are performed, alarm is
not activated even if the alarm signal is received.
REPORT number 1-8: OFF /ON Specify the terminal that transmits alarm input information to the controller.
ACTIVE STATE number 1-8: CLOSE /OPEN
Specify whether to receive alarm signal information with make or break
contact.
