14
FUNCTION
AREA1-8
OFF /ON-L/ON-M/ON-H
Set locations for motion detection sensors.
OFF : No movement detected.
ON–L: Detects movement at low sensitivity.
ON–M: Detects movement at intermediate sensitivity.
ON–H: Detects movement at high sensitivity.
ACTION
AREA1-8
OFF /***POS/TOUR1-16/
TRACE1-2/ALARM1-8/
AUX1 ON/AUX1 OFF/
AUX2 ON/AUX2 OFF
Set operations that will take place when sensors are activated.
OFF : No operation.
***POS : Presets to the designated position.
TOUR1–16: Activates the selected camera’s Tour sequence.
TRACE1, TRACE2: Activates selected trace functions.
AUX1 ON, AUX1 OFF, AUX2 ON, AUX2 OFF
: Performs specified operations at specified contact numbers.
ALARM1–8: Activates the alarm and performs the same operation as when
an alarm signal is received at the specified alarm number.
PRIVACY MASK (*1) SET /CLEAR/PATTERN
SET MASK1-8
When there are locations that are required to be kept out of view in a
camera scene, up to 8 of such locations can be masked out of view.
Setting Privacy Masking to ON automatically disables the Auto-Flip function.
Only two （ C-CC564 、 C-CC764 ） or only four （ C-CC574 、 C-CC774 ）
masking areas can be displayed on the same screen. Depending on the
masked area and its size, the number of masking areas that can be set
decreases.
CLEAR MASK1-8 - NO /YES Clearing the Privacy Masking.
PATTERN FULL /HALF
Two different patterns are available: One is a Full pattern that completely
hides the masked area and the other is a Half pattern that makes it
semi-transparent.
LANGUAGE
ENGLISH /DEUTSCH/
FRANÇAIS/ITALIANO
(*1) C-CC564 , C-CC574 , C-CC764 , C-CC774
(*2) C-CC564 , C-CC574
(*3) C-CC574 , C-CC774
