11
PRIORITY
number 1-8:
ALARM /MANUAL/TIMER
– 3s/5s/10s/15s/20s/30s/
45s/1min
Specify whether to display the set alarm ID on the screen and forcibly
execute alarm operation or give priority to operation when an alarm signal is
received.
ALARM : Ignores commands from the controller and starts alarm operation.
MANUAL : Initiates alarm operation only while operating the initial program.
TIMER : Initiates alarm operation after the preset time elapses. When the
initial program is operating, alarm operations are initiated
immediately.
ACTION
number 1-8: OFF /***POS/
AUX1 ON/AUX1 OFF/
AUX2 ON/AUX2 OFF/
TOUR1-16/TRACE1-2/HOME
Specify the camera’s operation (Action) when an alarm signal is received.
INTERVAL
number 1-8: 3s/5s/10s/15s/ 20s /
30s/45s/1min/3min/5min/LEVEL
Specify the period of time that alarm conditions are maintained when an
alarm signal is received.
RESET ACTION
number 1-8: OFF /***POS/
AUX1 ON/AUX1 OFF/
AUX2 ON/AUX2 OFF/
TOUR1-16/TRACE1-2/HOME
Specify the camera’s operation when alarm conditions are reset.
ALARM DATA
Alarm log recorded most recently takes precedence.
Up to 16 latest logs can be displayed.
AUX
AUX1
INITIAL STATE- OFF /OＮ
ON STATE- CLOSE /OPEN
TYPE - MOMENTARY /LATCH
ON TIME
-
NO LIMIT /1s/2s/3s/5s/
10s/20s/30s
The AUX1 is an open collector type contact. The controller’s auxiliary switch
is used to control it.
AUX2 (*2)
TYPE - MOMENTARY /LATCH
ON TIME
-
NO LIMIT /1s/2s/3s/5s/
10s/20s/30s
The AUX2 is a relay type contact. The controller’s defroster switch is used to
control it.
TIMER
PROGRAM
number 1-16: REPEAT
-
OFF /DAILY/M-F/WEEKLY
TIME
ACTION -
***POS /AUX1 ON/
AUX1 OFF/AUX2 ON/AUX2
OFF
TOUR1-16/TRACE1-2/HOME
CLEAR - NO/YES
Predetermined operations can be set to be performed at preset times.
Select the program from Preset Memory, Home Position Change, Auto
Operation, and Contact Control. The programs can also be set for several
types of operation, including “one time only,” “daily preset times,” and
“weekly.” Up to 16 programs can be set for a timer.
TIME DISPLAY 12H /24H The time display can be set to 12-hour or 24-hour display formats.
DATE DISPLAY
MM/DD/YY , DD/MM/YY,
YY/MM/DD
The date display can be set for month/day/year, day/month/year or
year/month/day display formats.
ENTER TIME Time can be set in the order of hour/ minute/ second.
ENTER DATE
The display formats of Month/Day/Year or Day/Month/Year follows the date
display setting.
