16
1.3. Setting Basic Operation
Menu screen to be displayed and the operation slightly differ depending on the connected equipment, however there is
no difference in basic operation.
More particularly, refer to the instruction manual, operation manual or set up manual enclosed with each equipment.
Menu key
• Use the Menu Start switch to enter the menu screen or exit the menu screen.
• Press the Menu Start switch to exit the menu screen in any screen status.
Joystick key
• Tilt the joystick upward or downward to move the cursor position on the setting items.
• Tilt the joystick left or right to change the setting contents.
• Used to rotate the camera when performing preset settings or Auto Mode camera settings.
Set key
Press the Set key to determine the setting items or setting contents, moving the cursor or to the next setting, followed by
screen change.
Clear key
• Press the Clear key to return the screen from the current screen (or status) to the last previous screen (status).
• Used to correct figures entered.
Numerical keypad
Used to enter camera number and camera position number.
Zoom key
Used to perform preset and zoom operation settings.
Focus key
Used to perform preset and focus operation settings.
[ Operation Method ]
C-RM500
Menu Screen Display
Menu Screen Exit
Menu Start switch
Setting contents Change
Tilt joystick
upward/ downward/ left/ right
Setting item selection
Tilt joystick
upward/ downward/ left/ right
Setting item determination Set key
Returning setting screen Clear key
Figure clear Clear key
Camera number setting
Position setting
Numerical Keypad
Zoom setting Zoom key
Focus setting Focus key
