27

Table 12 — DIP Switch Block S2 —

Accessory 1 Relay Options

LEGEND

NOTE: All other DIP switch combinations are invalid.

Table 13 — DIP Switch Block S2 —

Accessory 2 Relay Options

LEGEND

NOTE: All other switch combinations are invalid.

Auto Dehumidification Mode or High Fan Mode — Switch 7

provides selection of auto dehumidification fan mode or high

fan mode. In auto dehumidification fan mode the fan speed

relay will remain off during cooling stage 2 if terminal H is

active. In high fan mode, the fan enable and fan speed relays

will turn on when terminal H is active. Set the switch to ON for

auto dehumidification fan mode or to OFF for high fan mode.
Switch 8 — Not used.

Deluxe D Control Accessory Relay Configura-
tions —

The following accessory relay settings are applica-

ble for both Deluxe D controls only:
CYCLE WITH FAN — In this configuration, the relay will be

ON any time the Fan Enable relay is on.
CYCLE WITH COMPRESSOR — In this configuration, the

relay will be ON any time the Compressor relay is on.
DIGITAL NIGHT SET BACK (NSB) — In this configura-

tion, the relay will be ON if the NSB input is connected to

ground C.
NOTE: If there are no relays configured for digital NSB, then

the NSB and override (OVR) inputs are automatically config-

ured for mechanical operation.
MECHANICAL NIGHT SET BACK — When NSB input is

connected to ground C, all thermostat inputs are ignored. A

thermostat set back heating call will then be connected to the

OVR input. If OVR input becomes active, then the Deluxe D

control will enter Night Low Limit (NLL) staged heating

mode. The NLL staged heating mode will then provide heating

during the NSB period.

Water Valve (Slow Opening) —

If relay is config-

ured for Water Valve (slow opening), the relay will start

60 seconds prior to starting compressor relay.

Outside Air Damper (OAD) —

If relay is configured

for OAD, the relay will normally be ON any time the Fan

Enable relay is energized. The relay will not start for

30 minutes following a return to normal mode from NSB,

when NSB is no longer connected to ground C. After 30 min-

utes, the relay will start if the Fan Enable is set to ON.

START-UP

Use the procedure outlined below to initiate proper unit

start-up.
NOTE: This equipment is designed for indoor installation only.

Operating Limits

ENVIRONMENT — This equipment is designed for indoor

installation ONLY. Extreme variations in temperature, hu-

midity and corrosive water or air will adversely affect the

unit performance, reliability and service life.
POWER SUPPLY — A voltage variation of ± 10% of

nameplate utilization voltage is acceptable.
UNIT STARTING CONDITIONS — Depending on the

model, units start and operate in an ambient temperature of

45 F with entering-air temperature at 40 F or 50 F, entering-

water temperature at 20 F or 50 F and with both air and water at

the flow rates used.
NOTE: These operating limits are not normal or continuous

operating conditions. Assume that such a start-up is for the

purpose of bringing the building space up to occupancy

temperature. See Table 14 for operating limits.

1. Restore power to system.
2. Turn thermostat fan position to ON. Blower should

start.

3. Balance airflow at registers.
4. Adjust all valves to the full open position and turn on

the line power to all heat pump units.

5. Operate unit in the cooling cycle first, then the heating

cycle. Refer to Table 14 for unit operating limits. Al-

low 15 minutes between cooling and heating tests for

pressure to equalize.

NOTE: Two factors determine the operating limits of a unit:

entering-air temperature and water temperature. Whenever

any of these factors are at a minimum or maximum level,

the other two factors must be at a normal level to ensure

proper unit operation. See Table 14.

ACCESSORY 1

RELAY OPTIONS

DIP SWITCH POSITION

1

2

3

Cycle with Fan

On

On

On

Digital NSB

Off

On

On

Water Valve — Slow Opening

On

Off

On

OAD

On

On

Off

NSB — Night Setback
OAD — Outside Air Damper

ACCESSORY 2

RELAY OPTIONS

DIP SWITCH POSITION

4

5

6

Cycle with Fan

On

On

On

Digital NSB

Off

On

On

Water Valve — Slow Opening

On

Off

On

OAD

On

On

Off

NSB — Night Setback
OAD — Outside Air Damper

CAUTION

To avoid equipment damage, DO NOT leave system filled

in a building without heat during the winter unless anti-

freeze is added to system water. Condenser coils never

fully drain by themselves and will freeze unless winterized

with antifreeze.

WARNING

When the disconnect switch is closed, high voltage is

present in some areas of the electrical panel. Exercise

caution when working with the energized equipment.

Failure to heed this warning could lead to personal

injury.
