Carrier AQUAZONE PCV015-060 User Manual
Page 21
21
Table 3 — 50PCH,PCV Unit Electrical Data
LEGEND
*Units using 460-v and ECM (electronically commutated motor), modulating
HWR (hot water reheat), and/or internal secondary pump will require a neutral
wire from the supply side in order to feed accessory with 265-v.
NOTES:
1. HACR circuit breaker in U.S.A. only.
2. All fuses
3. Class RK-5.
50PCH,PCV
UNIT SIZE
VOLTAGE
CODE
RATED
VOLTAGE
V-Ph-Hz*
VOLTAGE
MIN/MAX
COMPRESSOR
STANDARD UNITS
UNITS WITH HIGH STATIC BLOWER
QTY
RLA
LRA
Fan Motor
FLA
Total Unit
FLA
MCA
Max Fuse/
HACR
Fan Motor
FLA
Total Unit
FLA
MCA
Max Fuse/
HACR
015
3
208/230-1-60
197/254
1
6.0
29.0
1.00
7.0
8.5
15
1.00
1.00
7.0
15
4
265-1-60
239/292
1
5.4
28.0
0.86
6.3
7.6
15
0.86
0.86
6.3
15
018
3
208/230-1-60
197/254
1
7.2
33.0
1.00
8.2
10.0
15
1.50
1.50
8.7
15
4
265-1-60
239/292
1
5.9
28.0
0.86
6.8
8.2
15
1.30
1.30
7.2
15
024
3
208/230-1-60
197/254
1
12.8
58.3
1.50
14.3
17.5
30
3.00
3.00
15.8
30
4
265-1-60
239/292
1
9.6
54.0
1.30
10.9
13.3
20
2.70
2.70
12.3
20
030
3
208/230-1-60 197/254
1
14.1
73.0
3.00
17.1
20.6
30
3.00
3.00
17.1
30
4
265-1-60
239/292
1
11.2
60.0
2.70
13.9
16.7
25
2.70
2.70
13.9
25
5
208/230-3-60
197/254
1
8.9
58.0
3.00
11.9
14.1
20
3.00
3.00
11.9
20
6
460-3-60
414/506
1
4.2
28.0
1.70
5.9
7.0
15
1.70
1.70
5.9
15
036
3
208/230-1-60
197/254
1
16.7
79.0
1.80
18.5
22.7
35
3.00
3.00
19.7
40
4
265-1-60
239/292
1
13.5
72.0
2.00
15.5
18.9
30
2.70
2.70
16.2
30
5
208/230-3-60
197/254
1
10.4
73.0
1.80
12.2
14.8
25
3.00
3.00
13.4
25
6
460-3-60
414/506
1
5.8
38.0
1.24
7.0
8.5
15
1.70
1.70
7.5
15
042
3
208/230-1-60
197/254
1
17.9
112.0
3.00
20.9
25.4
40
3.00
3.00
20.9
40
5
208/230-3-60
197/254
1
13.5
88.0
3.00
16.5
19.9
30
3.00
3.00
16.5
30
6
460-3-60
414/506
1
6.0
44.0
1.70
7.7
9.2
15
1.70
1.70
7.7
15
1
575-3-60
518/633
1
4.9
34.0
1.40
6.3
7.5
15
1.40
1.40
6.3
15
048
3
208/230-1-60
197/254
1
21.8
117.0
3.40
25.2
30.7
50
4.90
4.90
26.7
50
5
208/230-3-60
197/254
1
13.7
83.1
3.40
17.1
20.5
30
4.90
4.90
18.6
35
6
460-3-60
414/506
1
6.2
41.0
1.80
8.0
9.6
15
2.50
2.50
8.7
15
1
575-3-60
518/633
1
4.8
33.0
1.40
6.2
7.4
15
1.90
1.90
6.7
15
060
3
208/230-1-60
197/254
1
26.3
134.0
4.90
31.2
37.8
60
5.80
5.80
32.1
60
5
208/230-3-60
197/254
1
15.6
110.0
4.90
20.5
24.4
40
5.80
5.80
21.4
40
6
460-3-60
414/506
1
7.8
52.0
2.50
10.3
12.3
20
2.60
2.60
10.4
20
1
575-3-60
518/633
1
5.8
38.9
1.90
7.7
9.2
15
2.30
2.30
8.1
15
FLA
— Full Load Amps
HACR — Heating, Air Conditioning and Refrigeration
LRA
— Locked Rotor Amps
MCA
— Minimum Circuit Amps
RLA
— Rated Load Amps
Fig. 23 — Typical Single-Phase Line Voltage Power Connection
a50-8162
