Toa DP-K1 - Manual (Page 83)

83
The setting data of the file being edited can be printed.
Step 1. Select [File Print] from the menu.
Dialog for print area is displayed.
Step 2. Set the unit to be printed.
Select "Created" to print the created data of all the units.
To print the data of the arbitrary units, select "Selected," then click on the button of the units to be
printed.
Step 3. Set the memory to be printed.
Select "All" when printing all the data stored in 8 memories.
To print the data of the arbitrary memories, select "Selected," then click on the button of the memories
to be printed.
Step 4. If you do not want to print the default values for the Filter, Xover or Comp/Gate, click the check box for
"Do not print the default values."
Step 5. Press the [OK] button.
17. PRINTING THE SETTING DATA
