16.2. Method to Enable Communications between the PC and the Unit
The following 2 methods are available to permit the DP-K1 Setting Software installed in the PC to
communicate with the unit.
• Making communications after performing network settings
Step 1. Perform network settings by selecting [Remote
Connection Settings] and necessary settings to
control units, then designate the target unit. (See
the next page "Connection settings."
)
Step 2. Make communications in any of the following methods. (See
2-1. Make communications by selecting [Remote
Connect...].
2-2. Make communications by selecting [Remote
Bulk Transmission].
2-3. Make communications by selecting [Remote
Bulk Receiving].
• Making communications without performing network settings
When the system consists of only the units (10 units or less), PC, and switching hub that are connected to a
closed network, communications are enabled as follows without performing network settings.
Make communications with the unit by selecting [Remote
Simple Connection] from the menu.
Note
Up to 10 units can be connected using "Simple Connection."
When connecting 11 units or more to a PC, follow the procedures for "Making communications after
performing network settings" as described above.
