Toa FS-7000 SERIES Installation - Manual (Page 64)

64
7. TABLE FOR CABLES
Each number corresponds to the cable number in wiring diagrams.
7.1. Cables Supplied with Equipment
1
14
1
14
1
10
1
10
1
6
1
6
1
4
1
4
1
5
1
5
No. Cables Equipment Quantity
FS-7010CP 1
FS-7000JP
FS-7000EV
FS-7000RF
1
1
1
1
7 FS-7000JP
FS-7000GM
XAP14P
60 cm
Terminals to be connected
FS-7000CP [CP CONT] <--> FS-7010CP [CP CONT]
FS-7010CP [CP CONT] <--> FS-7010CP [CP CONT]
Terminals to be connected
FS-7000CP [JP CONT] <--> FS-7000JP [JP CONT]
FS-7010CP [JP CONT] <--> FS-7000JP [JP CONT]
XAP14P
SMR10P
Terminals to be connected
FS-7000CP [JP ZONE/GM GROUP CONT] <--> FS-7000JP [JP ZONE CONT]
FS-7000CP [JP ZONE/GM GROUP CONT] <--> FS-7000GM [GM GROUP CONT IN]
FS-7010CP [JP ZONE CONT] <--> FS-7000JP [JP ZONE CONT]
FS-7010CP [JP ZONE CONT] <--> FS-7000GM [GM GROUP CONT IN]
FS-7010CP [GM ZONE CONT] <--> FS-7000GM [GM ZONE CONT]
FS-7000GM [GM ZONE CONT] <--> FS-7000RF [GM ZONE CONT]
FS-7000GM [GM GROUP CONT IN] <--> FS-7000RF [GM GROUP CONT]
FS-7000GM [GM GROUP CONT IN] <--> FS-7000GM [GM GROUP CONT OUT]
SMR10P
XAP6P
2.5 m
2.5 m
SMR6P
XAP4P
2.5 m
XAP4P
Terminals to be connected
FS-7000CP [EV CONT] <--> FS-7000EV [EV CONT]
Terminals to be connected
FS-7000CP [RF CONT] <--> FS-7000RF [RF CONT]
XAP5P
60 cm
XAP5P
