5.8. FS-7000RF Remote Microphone Interface Panel
The FS-7000RF is used to connect the FS-7000RM to FS-7000 Series Voice Evacuation Systems. Up to 4
FS-7000RM units can be connected using the FS-7000RF. It is possible to control 50 speaker lines as well as
all-zone calls. Connection of the FS-7000GM enables broadcasts to be made to up to 20 zone groups.
[Front]
2
1
1. Power Indicator
Lights when power is supplied and the FS-
7000RF is ready for operation.
2. Fault Indicator
Lights if any failure is detected in communications
with the FS-7000RM and flashes if any failure
occurs on the FS-7000RF itself. (See page 77.)
