Carrier AQUAZONE RVC User Manual
Page 24
24
Table 5 — 50RHC,RVC Electrical Data
LEGEND
*Size 006 available in 50RHC unit only.
†Size 041 available in 50RVC unit only.
NOTES:
1. HACR circuit breaker in U.S.A. only.
2. All fuses Class RK-5.
50RHC,RVC
UNITS
VOLTS-PHASE
60 Hz
VOLTAGE
MIN/MAX
COMPRESSOR
FAN
MOTOR
FLA
TOTAL
UNIT
FLA
MIN
CIRCUIT
AMP
MAX
FUSE/HACR
RLA
LRA
006*
208/230-1
197/254
2.9
17.7
0.40
3.3
4.1
15
265-1
239/292
2.5
15.0
0.35
2.8
3.5
15
009
208/230-1
197/254
3.9
22.2
0.80
4.7
5.7
15
265-1
239/292
3.3
18.8
0.70
4.0
4.8
15
012
208/230-1
197/254
5.3
27.9
0.80
6.1
7.5
15
265-1
239/292
4.2
22.2
0.70
4.9
6.0
15
018
208/230-1
197/254
8.6
49.0
1.00
9.6
11.7
20
265-1
239/292
8.1
44.0
0.86
8.9
11.0
15
024
208/230-1
197/254
9.8
56.0
1.50
11.3
13.8
20
265-1
239/292
9.1
55.0
1.30
10.4
12.7
20
208/230-3
197/254
6.7
51.0
1.50
8.2
9.9
15
460-3
414/506
3.5
25.0
0.76
4.2
5.1
15
030
208/230-1
197/254
11.2
61.0
3.00
14.2
16.9
25
265-1
239/292
10.0
58.0
2.70
12.7
15.2
25
208/230-3
197/254
6.9
55.0
3.00
9.9
11.7
15
460-3
414/506
3.6
28.0
1.70
5.3
6.2
15
036
208/230-1
197/254
15.4
82.0
1.80
17.2
21.1
35
265-1
239/292
14.4
83.0
2.00
16.4
20.0
30
208/230-3
197/254
9.6
70.0
1.80
11.4
13.8
20
460-3
414/506
4.9
33.0
1.24
6.1
7.4
15
041†
208/230-1
197/254
16.2
96.0
3.00
19.2
23.2
35
208/230-3
197/254
10.3
75.0
3.00
13.3
15.8
25
460-3
414/506
4.3
40.0
1.70
6.0
7.1
15
575-3
518/633
4.3
34.0
1.40
5.7
6.8
15
042
208/230-1
197/254
17.1
105.0
3.00
20.1
24.3
40
208/230-3
197/254
10.7
85.0
3.00
13.7
16.4
25
460-3
414/506
5.3
42.0
1.70
7.0
8.3
15
575-3
518/633
3.7
31.0
1.50
5.2
6.1
15
048
208/230-1
197/254
18.3
102.0
3.40
21.7
26.3
40
208/230-3
197/254
12.6
91.0
3.40
16.0
19.2
30
460-3
414/506
5.7
42.0
1.80
7.5
8.9
15
575-3
518/633
4.7
39.0
1.40
6.1
7.2
15
060
208/230-1
197/254
25.6
170.0
4.30
29.9
36.4
60
208/230-3
197/254
14.7
124.0
4.30
19.0
22.7
35
460-3
414/506
7.4
59.6
2.50
9.9
11.8
15
575-3
518/633
5.9
49.4
1.90
7.8
9.3
15
FLA
— Full Load Amps
HACR — Heating, Air Conditioning and Refrigeration
LRA
— Locked Rotor Amps
RLA
— Rated Load Amps
