COPYRIGHT © 2014 RED.COM, INC
DSMC FAN 2.0 UPGRADE INSTRUCTIONS
955-0012, REV-D
|
16
4. Remove the top vent scoop from the DSMC BRAIN.
5. Use a T6 Torx driver (included) to remove the two (2) M2x0.4 x 4 mm cap screws from the exhaust fan pogo
cover (black plastic slip).
Remove Top
Remove Cap Screws
