TOP FAN COMPATIBILITY
The table below describes which top plates are compatible with the top fan. All compatible top plates provide
sufficient clearance for the top fan.
Once again making obsolescence obsolete, RED provides a replacement top vent scoop in each DSMC FAN 2.0
UPGRADE KIT (TOP and BOTTOM/TOP), so that you can install a compatible top plate along with your top fan.
TOP PLATE
PART NUMBER COMPATIBLE NOTES
EPIC-X top vent
scoop
125-2057
Yes
This top plate currently ships with EPIC-X cameras, and is
included in the DSMC FAN 2.0 UPGRADE KIT (TOP and BOT-
TOM/TOP) — EPIC as a replacement for incompatible top
plates.
SCARLET-X top
vent scoop 2.0
125-2057-02 Yes
This top plate is included in the DSMC FAN 2.0 UPGRADE KIT
(TOP and BOTTOM/TOP) — SCARLET as a replacement for
incompatible top plates.
DSMC TACTICAL
TOP PLATE 2.0
790-0383
Yes
This second generation DSMC TACTICAL TOP PLATE is spe-
cially designed to provide extra efficiencies and clearance for
the DSMC top fan.
EPIC-M top vent
scoop
125-2095
No
If you have an EPIC-M top vent scoop, install the replacement
EPIC-X top vent scoop included in the DSMC FAN 2.0 UP-
GRADE KIT (TOP and BOTTOM/TOP) — EPIC when installing
the top fan.
NOTE: Please contact
EPIC-M that has not already been sent in for the free upgrade
program. The upgrade program includes mechanical improve-
ments and additional mounting points. The upgrade should be
performed before you install the top fan.
SCARLET-X top
vent scoop
125-2100
No
If you have a SCARLET-X top vent scoop, install the replace-
ment SCARLET-X top vent scoop 2.0 included in the DSMC
FAN 2.0 UPGRADE KIT (TOP and BOTTOM/TOP) — SCARLET
when installing the top fan.
DSMC TACTICAL
TOP PLATE
790-0255
No
If you currently have an original DSMC TACTICAL TOP PLATE,
you can either send in your DSMC TACTICAL TOP PLATE and
receive credit toward the purchase of a new DSMC TACTICAL
TOP PLATE 2.0, or you can send in your DSMC TACTICAL
TOP PLATE for modification by RED free of charge.
NOTE: The part number of each top vent scoop is marked on the bottom of the top vent scoop.
NOTE: Any top vent scoop part number that is not listed in the table above is not compatible with the top fan.
For more details about the DSMC TACTICAL TOP PLATE modification and trade-in options, please contact
.
