PROHEAT G-I PCM SERVICE MANUAL
E-1
MODEL DESCRIPTIONS
E.
Please refer to the M-Series Parts Book at www.proheat.com for detailed part
descriptions and part numbers. Included in the parts book are optional features
such as a timer, coolant pump and associated installation equipment and
maintenance tools. The following information describes the general characteristics
of M-Series models covered in this manual: Heat Output, G-I PCM CANbus,
Voltage, Fuel Fitting optional configurations, and Air Intake optional configurations.
50,000 BTU/hr or 80,000 BTU/hr (15 kW or 23 kW).
The M-Series is available in either a 50,000 BTU/hr or 80,000 BTU/hr (15
kW or 23 kW) model.
Heat Output:
CANbus SAE J1939.
The M-Series Proheat Control Module (G-I PCM) is available with CANbus
SAE J1939.
G-I PCM:
12 V or 24 V.
The M-Series is available in either a 12 V (10 – 15 VDC) or 24 V (20 – 30
VDC) model.
Voltage:
Figure E-1.
MODEL:
M80-24V
S/N:
XXXXXX
POWER:
95 WATTS
FUEL TYPE: DIESEL
MAX PRESS: 2 BAR
OPER. VOLT: 20-30 VDC
HEAT OUTPUT: 24.0
KW
INSTALLATION DATE:
07
08
09
10
11
12
Made bt Teleflex Canada
Richmond BC Canada
PID 200101
