Troubleshooting
Troubleshooting Introduction
This troubleshooting chart outlines some common problems, their causes and possible corrective actions. If any
part or serial number information is available, provide it to the service technician when asking for assistance.
The Lippert Slideout System is only one of four interrelated slideout room system components. These four
components are: chassis, room, coach, and Lippert Slideout System. Each one needs to function correctly with the
others or misalignment problems will occur.
Every travel trailer has its own personality and what may work to fix one trailer may not work on another even if the
symptoms appear to be the same.
When something restricts room travel, system performance will be unpredictable. It is very important that slide
tubes be free of contamination and allowed to travel full distance (Stroke). Ice or mud buildup during travel is an
example of some types of contamination that can occur.
When you begin to troubleshoot the system, make sure the battery is fully charged, there are no visible signs of
external damage to the system and that all connections are secure.
During troubleshooting, remember that if you change something, that change may affect something else. Be sure
any changes you make will not create a new problem.
You can obtain additional information on the Lippert Slideout System by visiting
www.lci1.com/customerservice or
by calling 574-537-8900.
Problem Probable Cause Corrective Action
Room doesn't move when switch is
pressed
Restriction or obstruction inside or
outside of unit
Check for and clear obstruction
Low battery voltage, blown fuse,
defective wiring
Check battery voltage and charge
if needed. Find and check fuse,
replace if blown. Check battery
terminals and wiring. Look for
loose, disconnected or corroded
connectors.
Power unit runs but room does not
move
Restrictions both inside and outside
of unit
Check for and clear restriction
Power unit runs, room moves slowly Low battery, poor ground, extremely
low outdoor temperature
Charge battery and check ground
wire
Room drifts in both the in and out
positions
Check for leaks in the hydraulic
system
Tighten fittings
Air in system
After checking all connections, cycle
pump several times in and out
In the closed position, room drifts
out
Leaking cylinder seal See cylinder test next page
Fluid bypassing cylinder piston See cylinder test next page
Hose from pump is leaking Tighten fitting or replace hose
Air in system
After checking all connections, cycle
pump several times in and out.
Loose mounting bolts Tighten mounting bolts.
In the open position, room drifts in
Hose from pump is leaking Tighten fitting or replace hose
Leaking cylinder seal See cylinder test on next page
Fluid bypassing cylinder piston See cylinder test on next page
