Rev: 07.09.2014
Page 6
Hydraulic Through Frame Slideout Owners Manual
Maintenance
Inspection
After servicing the slideout system in any way, be sure to check the following:
1. Slideout stops are installed and adjusted properly.
2. Head assemblies are installed and adjusted properly.
3. System is mounted properly.
4. Cross shafts are mounted properly and clear all other components.
5. Gear packs function properly.
6. Manual override is accessible.
7. Outside seals compress when slideout is retracted.
8. Inside seals compress when slideout is extended.
9. Slideout extends and retracts smoothly.
10. Both sides of slideout are synchronized.
11. Any dirt or debris is cleaned from the interior or exterior of the coach.
System Maintenance
The Lippert Through Frame Slideout System has been static tested to over 4,000 continuous cycles without
any noticeable wear to rotating or sliding parts. It is recommended that when operating in harsh environments
(road salt, ice build up, etc.) the moving parts be kept clean. They can be washed with mild soap and water. No
grease or lubrication is necessary and in some situations may be detrimental to the environment and long term
dependability of the system.
Electrical System Maintenance
For optimum performance, the slideout system requires full battery current and voltage. The battery must be
maintained at full capacity. Other than good battery maintenance, check the terminals and other connections at
the battery, the control switch, and the system for corrosion, and loose or damaged terminals. Check motor leads
under the trailer chassis. Since these connections are subject to damage from road debris, be sure they are in good
condition.
NOTE: The Lippert Through Frame Slideout System is designed to operate as a negative ground system.
A negative ground system utilizes the chassis frame as a ground and an independent ground
wire back to battery is necessary. It is important that the electrical components have good wire to
chassis contact. To ensure the best possible ground, a star washer should be used. Over 90% of
unit electrical problems are due to bad ground connections.
Mechanical Maintenance
Although the system is designed to be almost maintenance free, actuate the room once or twice a month to keep
the seals and internal moving parts lubricated. Check for any visible signs of external damage after and before
movement of the travel trailer.
NOTE: For long-term storage: It is recommended that the room be closed (retracted).
