2x3 hydraulic through frame slideout assembly – Lippert Components Hydraulic Through Frame Slideout User Manual
Page 24
Rev: 07.09.2014
Page 24
2x3 Hydraulic Through Frame Slideout Webpage
Hydraulic Cylinder
Front Roller
Assembly
Inner Arm
Assembly
Outer Arm Assembly
Cylinder Mounting Bracket
Rear
Roller
Front
Roller
Wear Tab
Roller
Shaft
Section Assembly
2 x 3 Shorty Hydraulic Slideout
Roller
Rod & Pin
2X3 HYDRAULIC THROUGH FRAME SLIDEOUT ASSEMBLY
