Room bar measurement chart, A________ b________ c________ d – Lippert Components Hydraulic Through Frame Slideout User Manual
Page 15
Rev: 07.09.2014
Page 15
Hydraulic Through Frame Slideout Owners Manual
ROOM BAR MEASUREMENT CHART
SLIDEOUTS
Instructions:
1. Circle which side of your coach this room bar is for (Door Side or Off Door Side).
2. Enter the measurements for A, B, C, and D on the lines at the bottom.
DOOR SIDE
OFF DOOR SIDE
FRONT OF COACH
Room Bar
A________ B________ C________ D________
D
C
A
B
Room Bar
Brackets
