5x2.5 hydraulic through frame slideout assembly – Lippert Components Hydraulic Through Frame Slideout User Manual
Page 28
Rev: 07.09.2014
Page 28
2.5x2.5 Hydraulic Through Frame Slideout Webpage
Section View
Inner Arm
Assembly
Outer Arm
Assembly
Cross
Shaft Kit
Hydraulic
Cylinder
Head
Assembly
Front Cylinder
Mounting Bracket
Rear Cylinder
Mounting Bracket
Spur Gear
Gear Pack
Assembly
Wear Tab
Rear Roller
2.5X2.5 HYDRAULIC THROUGH FRAME SLIDEOUT ASSEMBLY
SLIDEOUTS
