Hydraulic Through Frame Slideout Owners Manual
Warning, Safety, and System Requirement Information
Description
The Lippert Hydraulic Through Frame Slideout System is a rack and pinion guide system, utilizing a hydraulic
cylinder to move the room assembly. The power unit drives the cylinder rod in a forward and backward motion to
move the slide room in and out. The Lippert Hydraulic Slideout System is designed to operate as a negative ground
system.
Safety Information
The “WARNING” symbol above is a sign that a service or maintenance procedure has a safety risk involved and may
cause serious injury or death if not performed safely and within the parameters set forth in this manual.
Always wear eye protection when performing service or maintenance to the vehicle. Other safety equipment to
consider would be hearing protection, gloves and possibly a full face shield, depending on the nature of the service.
This manual provides general service and maintenance procedures. Many variables can change the circumstances
of the service procedure, i.e., the degree of difficulty involved in the service operation and the ability level of the
individual performing the operation. This manual cannot begin to plot out procedures for every possibility, but will
provide the general instructions for effectively servicing the vehicle. In the event the skill level required is too high
or the procedure is too difficult, a certified technician should be consulted before performing the necessary service.
Failure to correctly service the vehicle may result in death, serious injury or voiding the warranty. The owner’s
manual for the unit may have more procedures for service and maintenance.
Failure to act in accordance with the following may result in death, serious injury, coach or property
damage.
The Lippert Hydraulic Through Frame Slideout System is intended for the sole purpose of extending and retracting
the slideout room. Its function should not be used for any other purpose or reason than to actuate the slideout
room. To use the system for any reason other than what it is designed for may result in damage to the coach and/
or cause serious injury or even death.
Before actuating the system, please keep these things in mind:
1. Parking locations should be clear of obstructions that may cause damage when the slideout room is
actuated.
2. Be sure all persons are clear of the coach prior to the slideout room actuation.
3. Keep hands and other body parts away from slideout mechanisms during actuation. Severe injury or
death may result.
4. To optimize slideout actuation, park coach on solid and level ground.
