2x2 hydraulic through frame slideout components – Lippert Components Hydraulic Through Frame Slideout User Manual
Page 23
Rev: 07.09.2014
Page 23
2x2 Hydraulic Through Frame Slideout Webpage
Callout
Part #
Description
A
123603
Hydraulic Trunion 38"
B
125653
Hydraulic Trunion 24"
C
133874
Hydraulic Trunion 30"
D
141109
O-Ring Face Seal Straight Fitting
E
173738
O-Ring Face Seal Elbow Fitting
F
120639
Hydraulic Interior Slideout Switch
G
140530
6 Prong Interior Switch with Wall Plate
A
B
C
D
E
F
G
2X2 HYDRAULIC THROUGH FRAME
SLIDEOUT DRIVE COMPONENTS
SLIDEOUTS
2X2 HYDRAULIC THROUGH FRAME SLIDEOUT COMPONENTS
