Parts list – Culligan Platinum Plus Series User Manual
Page 49
45
Parts List
Head Assembly
Item No.
No.Req’d
Part No.
Description
1
1
-
Backplate
2,3,4
1
01019693
Backplate Adapter Kit - Includes Backplate
Adapter, 4ea Tabs & 4ea Screws
5
3
-
Screw
6
2
-
Screw
7
1
01019650
Lower Support Plate
8 & 9
1
01019652
Gear Kit - Includes Shaft & Main Drive Gear
10
1
01019649
Upper Support Plate
11
1
01019656
Cam - 5 Pack
12
1
01019648
Motor
13
1
01019743
Screw - 10 Pack
14
1
01019651
Daughter Circuit Board
15
1
01018519
Circuit Board Mounting Plate
16
1
01018852
Circuit Board
17& 18
1
01018516
Front Enclosure w/ Label
19
1
-
Locking Nut
21 & 22
1
01019657
Auxilliary Switch w/ 2ea Screws
*
1
01018133
Transformer
