Summagrid IV 32

Example: C:\WINDOWS/SUMMA

[ENTER]

9. Install the Summagraphics Control Panel icon in one of the program manager

groups so that it is easily accessible:

Run Windows.

Open the Windows Program Manager by double-clicking on its icon.

Under the file dropdown menu, choose NEW.

The New Program Object dialog box appears. Select Program Item and
click OK.

The Program Item Properties dialog box appears. Type SUMMA in the
Description box. Enter the path name for the Summagraphics Control
Panel in the Command Line box and click OK. For example, if Windows is
installed on your C: Drive, in a directory called, WINDOWS, you would
type: C:\WINDOWS\SUMMA.EXE.

The SUMMA icon should appear in the current group’s window. If
desired, it may be dragged to a different group’s window.

10. To run the control panel, click on the SUMMA icon.
