PART # QTY. DESCRIPTION
PACKED LOOSE IN KIT
CANPY044 1 SPIRIT
Canopy
SPRTD01 1 SPIRIT
Decal
Sheet
SPRTF10
1
Shaped Balsa Nose Block
SPRTF12 1 ABS
Formed
Cockpit
SPRTP01 1 Full
Size
Plan
Sheet
SPRTP02 1 Instruction
Book
SPRTW15
2
Tapered Balsa Wing Tip Block
WIRES 10
1
36" Wire W/ Threaded Ends
ALUM010
1
Aluminum Wing Joiner
SUB-PACK
DIE-CUT
FUSE
PARTS
(SPRTA01)
SPRTF01 2 3/32"
Balsa Fuselage Sides,
Wing Saddle Tripler
SPRTF02 2 3/32" Balsa Fuselage Doublers
SPRTF03 1 1/8" Plywood Front Fuselage
Bottom
SPRTF04 1 3/32" Balsa Rear Fuselage
Sheeting
SUB-PACK DIE-CUT WING RIBS (SPRTA02)
SPRTW01 1 1/8" Balsa Ribs 1A,1B,3A,3B
SPRTW02 2 1/16" Balsa Ribs 2, 2S
SPRTW03 2 1/16" Balsa Ribs 2, 4-10
SPRTW07 2 1/16" Balsa Shear Webs
SUB-PACK MISC. DIE-CUT SHEETS
(SPRTA03)
SPRTF05 1 1/8" Plywood Formers and
Canopy Ends
SPRTF06 1 1/8" Balsa Canopy Base
SPRTS01 1 3/16" Balsa Tail Pans
SPRTW04 1 1/8"
Plywood
Dihedral
Braces
SPRTW05 1 1/16" Plywood Wing Joiners,
Towhook Plate, Spoiler Horn
SPRTW06 1 1/32" Plywood Polyhedral
Braces
SPRTW08 1 1/8" Plywood
Clamps
and
Gauges
SUB-PACK LONG STICKS fSPRTA04)
SPRTF07 4 1/8"
Square x 24" Balsa
Stringer
PART # QTY. DESCRIPTION
SUB-PACK LONG STICKS (Cont.)
SPRTF08 2 3/16" x 24" Balsa Triangle
SPRTF09 2 1/4"
Square x 18" Balsa
Pushrod
SPRTS02 3 3/16" x 3/8" x 30" Balsa Tail
Frame
SPRTS03 2 1/8" x 3/16" x 30" Balsa
SPRTW13 4 1/8" x 5/16" x 23-1/2" Bass-
wood Inner Spar
SPRTW14 4 1/8" x 5/16" x 15-1/8" Bass-
wood Outer Spar
SUB-PACK L.E. / T.E. / ELEVATOR / WING
SHEETING (SPRTA06)
SPRTS04 1 3/16" x 1-1/2" Tapered Balsa
Elevator
SPRTW10 1 Shaped
Balsa
Leading
Edges
SPRTW 11
2
1/4" x 1 -1/4" Tapered, Notched
Inner Wing T.E.
SPRTW12 2 1/4" x 1-1/4" Tapered. Notched
Outer Wing T.E.
SPRTW17 3 1/16" x 3 x 30" Balsa Wing
Sheeting
SUB-PACK HARDWARE AND SMALL
PARTS (SPRTMO1)
DOWEL030 2
1/4" x 3-1/2" Hardwood Wing
Dowel
DOWEL033 1
1/8" x 1-1/4" Canopy Hold
Down Dowel
NUTS001 3 4-40
Blind
Nut
NUTS002 1 4-40 Hex Nut
NYLON03 2 Small
Nylon Control Horn and
Nutplate
NYLON09 1 Nylon Hinges (12 per Tree)
NYLON17 2 Nylon
Clevis
SCRW001 4 2-56
x
3/8" Machine Screw
SPRTF11
2
1/4" x 3/8" x 2" Basswood
Servo Rail
WBNT148 1 4-40
Threaded
Towhook
WSHR005 1 #4
Flat
Washer
PARTS LIST
